JOHN DEERE 325 P-Tier Compact Track Loader
Compact Equipment
The John Deere 325 P-Tier Compact Track Loader delivers 70 net hp, excellent visibility, all-day cab comfort, easy serviceability, and strong versatility with a wide range of attachments for demanding construction jobs.
| Key Specs - Manufacturer | Yanmar® |
|---|---|
| Key Specs - Model | 4TNV98CT |
| Key Specs - Displacement (cu in.) | 203.0 cu in. |
| Key Specs - Rated engine speed (rpm) | 2500.0 rpm |
| Key Specs - Travel speed low (mph) | 5.2 mph |
| Key Specs - Travel speed high (mph) | 8.2 mph |
| Key Specs - Hydraulic horsepower standard flow (calculated) (hp) | 41.7 hp |
| Engine - Manufacturer | Yanmar® |
| Engine - Model | 4TNV98CT |
| Engine - Non-road emission standards | EPA Final Tier 4/EU Stage IV |
| Engine - Engine cylinders | 4 |
| Engine - Net power (SAE J1349, ISO 9249) at 2500 rpm (hp) | 70.0 hp |
| Engine - Rated gross power (ISO 14396) at 2500 rpm (hp) | 74.0 hp |
| Engine - Rated gross power (ISO 14396) at 2600 rpm (hp) | 74.0 hp |
| Engine - Peak torque at 1800 rpm (lb-ft) | 207.0 lb-ft |
| Engine - Displacement (cu in.) | 203.0 cu in. |
| Engine - Rated engine speed (rpm) | 2500.0 rpm |
| Engine - Torque rise percent at 1800 rpm (%) | 34.0 % |
| Engine - Aspiration | Turbocharged |
| Engine - Air cleaner type | Dry dual element |
| Cooling - Fan drive type | Variable-speed hydraulic drive standard / reversing fan drive optional |
Featured List
- Gross Power: 54.9 kW (74 hp)
- Net Power: 52.5 kW (70 hp)
- Rated Operating Capacity: 1176 kg (2,590 lb.)
- Operating Weight: 4313 kg (9,500 lb.)
Featured Content
Availability of over 100 John Deere attachments allows the 331 P‑Tier to move seamlessly between tasks such as grading, material handling, and site preparation. Advanced electrohydraulic controls make attachment operation smooth and responsive, while optional technology features—including grade‑management readiness—help operators work more efficiently and precisely as jobsite demands change.
Enhanced visibility features enable the operator to view the jobsite to be as precise and productive as possible while also increasing jobsite awareness. Equipped with optional deluxe LED lights and a rearview camera, operators benefit from increased visibility, especially in low light conditions. Clear sight lines improve safety and precision on the jobsite.
Easy serviceability minimizes downtime: the hood and side panels provide quick ground-level access to daily checks, and the cab swings up in under 5 minutes for major drivetrain access. JDLink™ alerts also help catch issues early.
