KLEEMANN MSC 953i EVO
Mobile Screening Plants
Properties
The mobile screening plant MOBISCREEN MSC 953i EVO is equipped with a 9.5 m2 screen casing. The triple-deck screening plant impresses with a feed capacity of up to 500 t/h. It is controlled using a modern control system. As a result, all functions are easy to control and operating statuses and machine functions can be viewed at any time.
-
Mobile triple-deck screening unit
-
Diesel-hydraulic drive
-
Classifying screen
-
Maximum feed size 100 x 160 mm
| BELT CONVEYOR, FINE GRAIN DISCHARGE - Width x length | 26 in x 5 ft 11 in |
|---|---|
| DISCHARGE CONVEYOR, OVERFLOW, LOWER DECK (MEDIUM GRAIN) - Discharge height approx. | 16 ft x 5 in |
| DISCHARGE CONVEYOR OVERFLOW CENTER DECK (MEDIUM GRAIN) - Length | 33 ft |
| TRANSPORT - Transport weight max. configuration approx. | 96,150 lbs |
| FEEDING UNIT - Max. feed size | 6.3 in x 4 in x 2 in |
| FINE GRAIN DISCHARGE CONVEYOR - Discharge height min. approx. | 10 ft x 10 in |
| FINE GRAIN DISCHARGE CONVEYOR - Width x length | 47 in x 26 ft 7 in |
| TRANSPORT - Transport height approx. (standard value) | 11 ft 1 in |
| DISCHARGE CONVEYOR, OVERFLOW, UPPER DECK (OVERSIZE GRAIN) - Discharge height approx. | 16 ft 6 in |
| FINE GRAIN DISCHARGE CONVEYOR - Discharge height max. approx. | 14 ft x 9 in |
| FEEDING UNIT - Feed height | 8 ft 3 in |
| DISCHARGE CONVEYOR OVERFLOW CENTER DECK (MEDIUM GRAIN) - Discharge height approx. | 16 ft |
| FINAL SCREENING UNIT - Upper deck (W x L) | 61 in x 20 ft x 0 in |
| FEEDING CONVEYOR - Length | 39 ft 4 in |
| FEEDING CONVEYOR - Width x length | 47 in x 39 ft 4 in |
| HOPPER DISCHARGE CONVEYOR - Length | 11 ft 6 in |
| HOPPER DISCHARGE CONVEYOR - Width x length | 47 in x 11 ft 6 in |
| FINE GRAIN DISCHARGE CONVEYOR - Length | 26 ft 7 in |
| DISCHARGE CONVEYOR OVERFLOW CENTER DECK (MEDIUM GRAIN) - Width | 26 in |
| TRANSPORT - Transport weight of basic plant | 80,700 lbs |
| OVERSIZE GRAIN CONVEYOR - Width approx. | 20 in |
| DISCHARGE CONVEYOR, OVERFLOW, UPPER DECK (OVERSIZE GRAIN) - Width x length | 20 in x 29 ft 2 in |
| FEEDING UNIT - Feed height - foldable slotted grate | 9 in |
| DISCHARGE CONVEYOR, OVERFLOW, LOWER DECK (MEDIUM GRAIN) - Width x length | 31 in x 33 ft 6 in |
| OVERSIZE GRAIN CONVEYOR - Length approx. | 29 ft 2 in |
| TRANSPORT - Transport length approx. | 58 ft 11 in |
| POWER SUPPLY UNIT - Drive concept | Diesel-hydraulic |
| POWER SUPPLY UNIT - Power supply unit output | 131 hp - 133 hp |
| FINAL SCREENING UNIT - Type | Triple-deck classifying screen |
| TRANSPORT - Transport width approx. | 10 ft 6 in |
| FEEDING UNIT - Hopper volume | 10.5 yd³ |
Featured Content
The MOBISCREEN mobile screening plants are used for screening almost all natural stone and in recycling.
Classifying screens are used to obtain exact fractions. The plant can be adapted individually to the application through the selection of screen surfaces, the screen inclination, etc.
Recommended use
Classifying screens for screening in natural stone applications up to 160 mm feed size
Triple-deck screens for classifying up to 4 fractions
Extensive range of screen surfaces
Feed capacity of up to 800 t/h
During the daily routine, screen surfaces are really put to the test. To guarantee long-term, reliable screening to the desired final grain size, the screen surfaces from KLEEMANN are made of particularly wear-resistant spring wire steel or round wire.
Thanks to the double-anchoring at the crossings, they have a high mesh stability for uniform screening. The screening result itself is determined by numerous factors. The most important influence factors include the grain shape, the humidity content and the feed volume.
The low fuel consumption can be reduced even further with the optional Start-Stop system.
A probe detects if no material is supplied over a defined period and engine speed is reduced automatically. Fuel consumption and wear on the engine, belts and support rollers are reduced.
If the material starts being supplied again, the plant is restarted and moves to production mode. Automatic operation ends if no material is subsequently conveyed for a defined period – with an option for switching off the engine.
Electricity is often cheaper than diesel. Added to this are ecological, legal or social provisions that often restrict the use of diesel.
The screening plants are equipped with a Dual Power System with two electric motors each with 37 kW (50 PS) for high work output combined with low fuel consumption. Connection is made via an electrical device. This permits a quick switch between two power sources (diesel engine or external power supply). Users thus remain flexible and the pollutant emission is reduced.
Fast and convenient service is possible on all MOBISCREEN EVO screening plants thanks to very easy accessibility or all components. All function- and safety-related hydraulic cylinders are equipped with safety valves (lowering/brake holding valves); each cylinder remains in its current position in the event of shutdown or malfunctioning. Furthermore, different critical areas on the machine are equipped with contact protection.
Additional safety is available in the form of spraying, LED and halogen lighting.
