  • Additional Standard Equipment:

    Back-up alarm
    Rotating safety beacon
    Gauge package (oil pressure, hour meter, voltmeter, electric fuel gauge, water temp, tachometer)
    Glow plugs
    Vandalism protection covers
    Horn
    Wiring for sonic augers, sensors and cords




  • Screed Extensions:

    Two 44” (1.11 m) screed extensions hydraulically operated
    To eliminate seams, the heated extensions have adjustable angle of attack and mounted flush with the main screed
    Includes replacement .25” (.006m) AR 400 bottom wear plates
  • Screed Heat - Propane (Standard):: Screed Heat - Propane (Standard):

    Two 54,000 BTU propane burners on main screed
    Each extension has one 36,000 BTU propane burner
    One 36,000 BTU burner ignitor
    Performance specs: Basic: 8’ (2.44 m) Maximum: 15’ (4.57 m)
    Main screed: .375” (.01 m) AR400 steel, 15” (.38 m)
    Extensions: .25” (.006 m) AR400 steel, 7” (.178 m)
    Extensions length: 3’ 6” (1.070 m)
    Walkway width: 12” (.305 m)





  • Optional Equipment:

    Electric Legend screed 8’ to 15’ (2.438 m x 4.572 m)
    14” (.356 m) polyurethane pad track
    High-deck configuration
    Truck hitch
    Second seat, low deck configuration only
    LED work light package
    Sonic auger, sensors and cords
    Electric screws for grade controls
    Wiring only, grade controls (TopCon), includes A/M modules
    Sonic grade controls, one side (TopCon)
    Dual grade controls (TopCon P-32 system), includes electric screws
    Hose reel, limited to two









  • Push Rollers:

    Two 3” (.076 m) diameter rollers with sealed bearings mounted on swivel frame
  • Operator’s Controls:

    All control levers are on the left side
    Right side levers include left and right drive control, right auger, right screed extensions, hopper and cut-offs
    Dash slides from left to right
  • Screed:

    Legend full floating 22” (.559 m) screed, consisting of a 15” (.381 m) by 8’ (2.438 m) main screed
    Constructed of .375” (.010 m) HARDOX 400 bolt-on wear plates for easy replacement
    Wear plate has integral bullnose on front
  • Paving Depths:

    Manually operated tow point screws with optional toggle switches connected to a 6” (152 mm) electric screw to control depth to allow operation from either side of paver
    Includes manual flight screws positioned on the screed
    Depth: 0” to 6” (.152 m)
  • Dimensions:

    Length: 12’ 9” (3.88 m)
    Width: 8’ 6” (2.59 m) transport
    10’ (3.05 m) hopper wings down
    Height: 8’ 4” (2.54 m)
    Total Weight (with screed): 15,800 lbs. (7,167 kg)


  • Operator’s Platform (Optional High Deck):

    Full machine width platform with both right and left hand seats
    4’ 6” (1.371 m) above ground
    Includes a lockable cover for the instrument panel
  • Screed Crown/Invert:

    Equipped with a crown/invert adjustment allowing at least 2” (.051m) of crown and 1.5” (.038 m) of valley
    Includes a leveling indicator for the operator to know when the screed is level
  • Hopper:

    Dual 36” (.914 m) feeding conveyors
    Each conveyor is independent with automatic cut-offs
    Conveyor is hydraulically raiseable to allow for cleaning and service
    Hopper size: 7.5 ton (6,804 kg) – high deck
    Hopper height: 22” (.559 m)


  • Screed End Gates:

    Equipped with vertical height adjustment and tilt
  • Washdown System:

    Electric HD pump with one 15’ x .3125” (4.572 x .008 m) diameter hose and two hose wraps
  • Under Auger Material Cutoff:

    Two independent hydraulically operated 4’ (1.219 m) wide gates located under the augers and constructed of at least .25” (.006 m) A-36 plate steel
  • Track Drive System:

    Hydrostatically powered, self-cleaning crawler type tracks consisting of drive sprocket, four rollers and hydraulically adjustable front idler
    Drive mechanism is torque hub driven which consist of two speeds and obtained by means of a toggle switch
    Fail safe brakes with anti-creep function
    Track size: 12” wide x 77” long (.305 x 1.956 m) steel

  • Screed Vibration:

    Equipped with a hydraulic vibrator capable of producing 2,400 vibrations per minute
  • Training, Support and Company:

    Training and support manuals
    Optional on-site operator training by Dealer
    One-year, unlimited hours warranty against any manufacturer defects
    Extended warranty available
    50+ years manufacturing experience
    ISO 9001 Certified
    Manufactured in the USA




  • Paving Widths:

    Variable up to 15’ (4.6 m)
  • Operator’s Platform (Optional Low Deck):

    Seat mounted on the screed
    Can be moved from left or right or removed for standing
  • Engine:

    Kubota, V2607-E4B
    Tier 4 Final – 67hp (49.9kW) @ 2,400 RPM
  • Capacities:

    Fuel: 17 gallons (66.5 l)
    Hydraulic Reservoir: 40 gallons (151 l)
    Washdown tank: 7 gallons (27 l)
  • Steering:

    Independent hydrostatic steering from the left or right side of machine
  • Material Augers:

    Two independent automatic or manual operated hydraulic cast segmented augers constructed with .625” (.016 m) AR 4140 HT (heat treated) steel with replaceable flights
    Augers are 9” (.229 m) diameter
  • Hydraulic System:

    Variable volume hydraulic pumps for each drive
    A constant volume pump for conveyors and a constant volume pump for all other hydraulic functions
    Hydraulic reservoir: 40 gallons (151 l)
    Hydraulic oil: all weather, all temperature
