  • Specs - Infeed System

    Infeed opening: 60? x 46? (152.4 cm x 116.8 cm)

    Variable speed infeed system consists of one 33? (83.82 cm) diameter top compression feed roll with internal drive and an 15’5? long x 60 3/8? (4.7 m x 153 cm) wide live floor equipped with four strands of WDH-120 chain in a staggered configuration with direct drive.


  • Specs - Options
    • Electric power
    • 12- or 16-knife chipper drum assembly
    • Variety of grates sizes available
    • Hydraulic rod puller
  • Specs - Hammermill and Grates

    36? x 61-3/8? (91.4 cm x 155.9 cm) hammermill system constructed of heavy-duty 25-½” (64.7 cm) diameter rotor, (17) 1-1/8? (44 cm) thick two-piece laser-cut rotor plates to ensure precision and enforce steel strength. The plates are keyed on an 8-3/8? (21.27 cm) diameter shaft with two 5-3/16? (13.17 cm) bearings and eight 2-¼” (5.7 cm) hammer retaining rods. Hammermill pattern consists of (18) 2? (5.08 cm) balanced forged steel heavy-duty hammers, (18) 3-1/16? (7.7 cm) wide double-edged replaceable inserts and 18 rakers.


  • Specs - General

    Length (transport) wheeled: 42? (12.8 m)
    Length (operating) wheeled: 63? (19.2 m)
    Height wheeled: 13’3? (4.04 m)
    Height (operating) wheeled: 16’9? (5.1 m)
    Width wheeled: 10’11” (3.33 m)

    Length (transport) tracked: 45? (13.72 m)
    Length (operating) tracked: 61’10” (18.85 m)
    Height tracked: 11’11” (3.63 m)
    Height (operating) tracked: 16’4? (4.98 m)
    Width tracked: 11’3? (3.43 m)


    Gross weight wheeled: 75,660 lbs. (34,320 kg)
    Axle weight: 51,600 lbs. (23,405 kg)
    Tongue weight: 24,060 lbs. (10,915 kg)

    Gross weight tracked: 88,640 lbs. (40,206 kg)


    Engine: CAT
    Horsepower: 1050 HP (783 kW)


    Fuel capacity (tank) wheeled: 370 gallons (1,400 litres)
    Hydraulic oil capacity wheeled: 187 gallons (708 litres)

    Fuel capacity (tank) tracked: 340 gallons (1,287 litres)
    Hydraulic oil capacity tracked: 267 gallons (1,010 litres)


    Screen Area: 4,414 sq in (28,477 sq cm)


    Brakes: air

    Towing arrangement:fifth wheel


    Dust suppression system

    Hydraulically operated debris containment door

    Remote control with tethered back-up system

    Automatic reversing fan system

    Externally adjustable break-away torque limiter

    Magnetized end pulley with collecting slide tray for ferrous metal removal

    11 HP (8.2 kW) air compressor with lockable enclosure


  • Specs - Discharge System

    Discharge system consists of a hydraulically driven, horizontal 48? wide x 22? (122 cm x 6.7 m) long aggregate belly belt conveyor discharging onto a 36? (91.44 cm) wide stacking conveyor with hydraulic fold for transport.
