  • Specs - Infeed System

    Infeed opening: 34? x 57? (86.4 cm x 114.8 cm)

    Variable speed infeed system consists of one 22? (55.8 cm) diameter top compression feed roll with internal drive and a 57? wide x 9’7? (144.8 cm x 2.9 m) long live floor with four strands of WDH-110 chain in a staggered configuration.


  • Specs - Options
    • Electric power
    • Single Axle Option
    • Live floor equipped with slat chain
    • 12- or 16-knife chipper drum assembly
    • Variety of grates sizes available
    • 4? (1.22 m) extended infeed
  • Specs - Hammermill and Grates

    23-¾” x 53-1/8? (60.32 cm x 134.9 cm) hammermill system constructed of heavy-duty 16? diameter rotor, (23) 1-1/8? (2.85 cm) thick two-piece laser-cut rotor plates to ensure precision and enforce steel strength. The plates are keyed on a 4-1/2? (11.43 cm) diameter shaft with two 3-7/16? (8.73 cm) bearings and eight 1-¼” (3.17 cm) hammer retaining rods. Hammermill pattern consists of (22) 1-¼” (3.17 cm) forged steel heavy-duty hammers, and (22) 2-1/16? (5.24 cm) wide double-edged replaceable inserts and 22 rakers.


  • Specs - General

    Length wheeled: 33’8? (10.26 m)
    Height wheeled: 11’6? (3.5 m)
    Width wheeled: 7’10” (2.39 m)

    Length tracked: 30? (9.1 m)
    Height tracked: 11’6? (3.5 m)
    Width tracked: 8’6? (2.6 m)


    Gross weight wheeled: 30,660 lbs. (13,910 kg)
    Axle weight: 23,920 lbs. (10,850 kg)
    Tongue weight: 6,720 lbs. (3,050 kg)

    Gross weight tracked: 32,000 lbs. (14,515 kg)


    Engine: CAT
    Horsepower: 275 HP to 300 HP (205 kW to 224 kW)


    Fuel capacity (tank): 90 gallons (340 litres)
    Hydraulic oil capacity: 92 gallons (348 litres)


    Screen Area: 2,585 sq in (16,677 sq cm)


    Brakes: air

    Towing arrangement: fifth wheel/pintle hitch


    Dust suppression system

    Manually operated debris containment door

    Remote control with tethered remote back?up system

    Magnetized end pulley with collecting slide tray for ferrous metal removal

    Air compressor with 11-HP (8.2 kW) motor

    Break-away torque limiter


  • Specs - Discharge System

    Discharge conveyor system consists of one hydraulically driven continuous belt with 40? wide x 17’6? long belly and stacking conveyor.
