  • Specs - General

    Length (transport) wheeled: 38’8? (11.78 m)
    Length (operating) wheeled: 58’8? (17.88 m)

    Height (transport) wheeled: 13’2? (4 m)
    Height (operating) wheeled: 17? (5.18 m)

    Width wheeled: 10’8? (3.25 m)

    Length (transport) tracked: 38’2? (11.63 m)
    Length (operating) tracked: 58’5? (17.8 m)

    Height (transport) tracked: 12? (3.66 m)
    Height (operating) tracked: 16’4? (4.99 m)

    Width tracked: 10’4? (3.15 m)


    Gross weight wheeled: 57,420 lbs. (26,045 kg)
    Axle weight: 36,240 lbs. (16,450 kg)
    Tongue weight: 21,180 lbs. (9,610 kg)

    Gross weight tracked: 66,700 lbs. (30,255 kg)


    Engine: CAT
    Horsepower: 540 HP to 760 HP (402 kW to 566 kW)


    Fuel capacity (tank): 280 gallons (1,059 litres)
    Hydraulic oil capacity: 187 gallons (708 litres)


    Screen Area: 3,538 sq in (22,826 sq cm)


    Brakes: air

    Towing arrangement: fifth wheel


    Dust suppression system

    Hydraulically operated debris containment door

    Remote control with tethered back-up system

    Externally adjustable break-away torque limiter 30-hammer hammermill pattern

    Magnetized end pulley with collecting slide tray for ferrous metal removal

    Automatic reversing fan system

    11 HP (8.2 kW) air compressor with lockable enclosure




  • Specs - Infeed System

    Infeed opening: 59?¾” x 38? (151.76 cm x 96.52 cm)

    Variable speed infeed system consists of one 30? (76.2 cm) diameter top compression feed roll with internal drive and a 16? long x 59?¾” (5.5 m x 151.8 cm) wide live floor equipped with four strands of WDH-110 chain in a staggered configuration.


  • Specs - Hammermill and Grates

    28? x 60 3/8? (71.12 cm x 153 cm) hammermill system constructed of heavy-duty 17 5/8? (44.8 cm) diameter rotor; 17, 1 1/8? (2.86 cm) thick, two-piece laser-cut rotor plates to ensure precision and enforce steel strength. The plates are keyed on a 5 7/8? (44.77 cm) diameter shaft with 3 15/16? (10 cm) bearings on both ends of the rotor and eight 2? (5.08 cm) hammer retaining rods. Hammermill pattern has 18, 2? (5.08 cm) balanced forged heavy-duty hammers, 18, 3 1/16? (7.78 cm) wide, double-edged replaceable inserts and 18 rakers.


  • Specs - Discharge System

    Discharge system consists of a hydraulically driven, horizontal 48? x 17’9? (122 cm x 5.41 m) aggregate belt conveyor discharging onto a 36? (91.44 cm) stacking conveyor with hydraulic fold for transport.


  • Specs - Options
    • Electric power
    • 12- or 16-knife chipper drum assembly
    • Variety of grates sizes available
    • Hydraulic rod puller
    • 320L Caterpillar undercarriage
