  • Specs - Infeed System

    Infeed opening: 66? x 50? (167 cm x 127 cm)

    Variable speed infeed system consists of one 36? (91.44 cm) diameter top compression feed roll with internal drive and a 17’6? long x 64? (5.3 m x 162 cm) wide live floor equipped with five strands of WDH-120 chain in a staggered configuration.


  • Specs - Discharge System

    Discharge system consists of a hydraulically driven, horizontal 48? wide x 19? (121.92 cm x 5.79 m) long aggregate belly belt conveyor discharging onto a 40? x 31? (101.6 cm x 9.45 m) stacking conveyor with hydraulic fold for transport.


  • Specs - General

    Length (transport) wheeled: 44? 11? (13.69 m)
    Length (operating) wheeled: 68’10” (20.98 m)
    Height (transport) wheeled: 13’6? (4.11 m)
    Height (operating) wheeled: 19’3? (5.87 m)
    Width wheeled: 11’10” (3.61 m)

    Length (transport) tracked: 44’9? (13.64 m)
    Length (operating) tracked: 67’1? (20.45 m)
    Height (transport) tracked: 11’11” (3.63 m)
    Height (operating) tracked: 18’6? (5.69 m)
    Width tracked: 11’11” (3.63 m)


    Gross weight wheeled: 91,440 lbs. (41,476 kg)
    Axle weight: 59,400 lbs. (26,945 kg)
    Tongue weight: 32,000 lbs. (14,515 kg)

    Gross weight tracked: 109,120 lbs. (49,500 kg)


    Engine: CAT
    Horsepower:  1125 HP to 1200 HP (838 kW to 894 kW)


    Fuel capacity (tank) wheeled: 390 gallons (1,478 litres)
    Hydraulic oil capacity wheeled: 335 gallons (1,268 litres)

    Fuel capacity (tank) tracked: 390 gallons (1,478 litres)
    Hydraulic oil capacity tracked: 335 gallons (1,268 litres)


    Screen Area: 5,661 sq in (36,522 sq cm)


    Brakes: air

    Towing arrangement: fifth wheel


    Dust suppression system

    Hydraulically operated debris containment door

    Remote control with tethered back-up system

    Automatic reversing fan system

    Externally adjustable break-away torque limiter

    Magnetized end pulley with collecting slide tray for ferrous metal removal

    11-HP (8.2 kW) air compressor with lockable enclosure


  • Specs - Hammermill and Grates

    42? x 66-5/8? (106.68 cm x 169.2 cm) hammermill system constructed of heavy-duty 28? (71 cm) diameter rotor, (18) 1-3/8? (3.5 cm) thick two-piece laser-cut rotor plates to ensure precision and enforce steel strength. The plates are keyed on a 9? (22.9 cm) diameter shaft with 5-3/16? (13.18 cm) bearings and eight 2-½” (6.35 cm) hammer retaining rods. Hammermill pattern has (18) 2-¼” (5.7 cm) balanced forged steel hammers, (18) 3-5/8? (47.3 cm) wide double-edged replaceable inserts and 18 forged rakers.


  • Specs - Options
    • Electric power
    • Variety of hammermill patterns
    • 14-knife chipper drum assembly
    • Variety of grates sizes available
    • Hydraulic rod puller
    • 330L Caterpillar Undercarriage
